Boost Factory Turbo Oil & Coolant Line kits For RB25 Spectrum Turbos. RWD ONLY

There are 2 options of coolant line kits available! please read below and make your selection. These kits when installed correctly eliminate the chance of unwanted leaks and provide a high quality appearance.

 Kit #1

This Kit is a semi direct bolt on for the RB25 Spectrum Turbos , This kit uses a weld on bung at the rear of the intake manifold eliminating the often corroded coolant port, this is significantly more work as you are required to remove the intake and have the bung welded on to the manifold, this leaves a very clean and tight to the back of the head fitment. for the coolant return line. This Return line may require a heat sleeve and is included in the kit.

This kit contains:

Oil Feed
-4AN To M12 X 1.25MM Oil Feed Fitting + Copper Washer
-4 AN Banjo Bolt & Banjo
-4 AN Feed Line

Coolant Feed & Return
-6 To M14 X 1.5MM Coolant To Turbo Fittings X2 + Copper Washer
-6 AN Coolant Feed Line
-6 AN Coolant Return Line
-6 Banjo To Coolant Feed
-6 AN Weld On Bung For Return Line
-Heat Sleeve

Oil Drain
-10 To BSPT Oil Drain Adaptor
-10 AN Oil Drain Flange
-10 AN Oil Drain Line

Kit #2

This Kit is a direct bolt on line kit for the spectrum turbos, This kit uses all parts and fittings of the correct thread pitch and size to leave a seamless and quick install. The coolant return line in this kit utilises a heat  rubber hose to be routed around the back of the cylinder head that fits onto the OEM coolant return port.
this hose may require a line heat sleeve and is included in the kit

Oil Feed
-4AN To M12 X 1.25MM Oil Feed Fitting + Copper Washer
-4 AN Banjo Bolt & Banjo
-4 AN Feed Line

Coolant Feed & Return
-6 To M14 X 1.5MM Coolant To Turbo Fittings X2 + Copper Washer
-6 AN Coolant Feed Line
-6 Push Lock To Rubber Coolant Return Line
-2 Hose Clamps
-6 Banjo To Coolant Feed
-Heat Sleeve

Oil Drain
-10 To BSPT Oil Drain Adaptor
-10 AN Oil Drain Flange
-10 AN Oil Drain Line
